(1) Perfect combination of servo motors and drives (controllers) in France VMMORE series, superior quality equipment, simple system structure, the system is stable and reliable, less maintenance, reduce the loss caused by downtime.
(2) Servo motor comes with encoder, the calculation of position is very accurate, it comes with displacement memory function. There is no accumulated error, and the stability of the accuracy can be guaranteed for a long time. Order arrangement accuracy ± 1.0mm. Servo motor sensitive, fast arrange order, reduce order arrangement time to 1-3 seconds.
(3) NSK bearings, Taiwan mute high precision screw guide rail. Ensure order arrangement high precision.
(4) Main electric components and cabinets are equipped with industrial air conditioner to ensure the stability of the equipment and prolong the service life.
(5) Hard alloy steel thin blade, diamond grind wheel.
(6) High strength high precision guide rail installation beam
(7) Stainless steel plate, paper guide frame.
(8) The system is based on EtherCAT bus, which is a mature industrial control bus, an international standard motion control protocol V2.0. based, which has fast communication speed and strong anti-jamming, advanced motion control protocol can achieve a combination of various optimization algorithms, accurate positioning, single row quickly.
(9) Computer order size, knife block, line shift dynamic display, which can monitor the production status; trimming parameter, the position of each cutter and line wheel is calculated by computer, and the error is eliminated. Servo motor dynamically micro trimming adjustment and scorer pressing device, more accurate; the order can be pre input, and can realize the insertion of a single, modify, A variety of functional filling orders; the scorer wheel depth and scorer type automatically controlled by computer.
(10) The adoption of an internationally available full open communication protocol that can be connected to any production management system or ERP;
(11) Remote monitoring: to support remote monitoring through Ethernet or 4G wireless network card to reduce the amount of after-sales service
(12) Down slitting type, the slitting edge accurate, the surface for printing is clean to avoid the edge or crushing or debris on the board. （might select top slitting structure）
(13) Independent paper guiding mechanism is more conducive to the creasing and cutting accuracy of the board, by Inovance inverter control;
(14) The knife felt lifting mechanism, very conducive to the paper.
(15) With pre pressure scorer, can be adapted to any weight cardboard indentation. (zero pressure line structure without preloading)
(16) Male to male, mail to female and male to flat, the choice of multiple indentation, linear conversion time1-3s.
(17) Indentation system flexibility, automatic servo adjustment when order changing;
(18) Full automatic waste suction system, when changing the single side of the suction port to follow the edge of the knife automatic adjustment
(19) independent grinding lubricant cooling system, prolong the service life of the cutter
(20) maximum speed: 150-350m/min
(21) the minimum longitudinal distance: 155 mm
(22) the minimum line distance: 120 mm (optional zero line structure)
(23) the line clearance adjustment: 1-10mm
(24) scheduling time: 1-3
(25) order change precision: ±1.0mm
